Product Details:
|
| Rated Traction Weight: | 500/1000/2000/3000kg | Platfor Size: | 1300x800mm |
|---|---|---|---|
| Lifting Motor Power: | 750/1500kw | Overall Weight: | 198-268kg |
| Lift Mechanism: | Scissor Lift | ||
| Highlight: | 3000kg Aerial Platform Lift,Scissor Aerial Platform Lift,3000kg scissor boom lift |
||
| Model | HIW1.0EU | HIW2.0EU | HIW4.0EU | HIW3.0EU | |
| Rated traction weight | kg | 500 | 1000 | 2000 | 3000 |
| The max. lifting height | mm | 1040 | 1040 | 1040 | 1040 |
| Lowered mast height | mm | 190 | 190 | 190 | 190 |
| Platfor Size | mm | 1300x800 | 1300x800 | 1300x800 | 1300x800 |
| Lifting time | S | 12-18 | 20-25 | 35-45 | 36-46 |
| Falling time | S | 10-16 | 17-22 | 31-41 | 30-40 |
| Hydraulic tank capacity | L | 2 | 2 | 2 | 2 |
| Lifting motor power | V | 220 | 220 | 220 | 220 |
| W | 750 | 750 | 750 | 1500 | |
| Overall weight | Kg | 198-108 | 210-220 | 250-260 | 258-268 |
Features
1.The lift is smooth and the load is large.
2.Improve work speed and efficiency.
