Product Details:
|
| Load Capacity: | 2T | Load Center: | 500mm |
|---|---|---|---|
| Lift Height: | 3000~5000mm | Fork Length: | 1220mm |
| Condition: | New | Min. Lifting Height: | 3000mm |
| Weight: | 4300KGS,1500Kg-4150kg | ||
| Highlight: | 2Ton Reach Truck Forklift,JAC Reach Truck Forklift,JAC standup reach truck |
||
JAC 2.0 Ton Electric Reach Truck / Electric Stacker/Mast Move Forward
Product description
The rough terrain forklift is an ideal piece of material handling equipment for outdoor construction and loading activities. This selection of forklift truck features large pneumatic tires, usually with deep treads enabling the operators to drive on rough road or ground cover without sliding or slipping. In addition, all terrain forklifts can also work well on paved ground, allowing one unit to be transported from outside area into warehouses and other places.
Features
1. The reach forklift truck is designed with advanced AC control system which eliminates the demand for replacement of motor brushes, and also comes an intelligent regenerative brake system.
2. It offers 4-level adjustable driving speed from 3km to 10km.
3. Due to the EPS (electric power steering) system, the reach truck features easy, flexible and much safer steering operation.
4. Via the joystick supporting finger-tip control, the warehouse equipment supports adjustment of driving speed, lifting and lowering speed, as well as opening and closing of the stabilizer.
5. Stabilizers (at certain lifting height), which can work manually or automatically, are available to enhance stability and safety of the electric reach truck when stacking cargo.
6. The electric forklift truck supports handling of two pallets at the same time when the forks are lifted up.
Structural Advantages of the Reach Truck
1. Although with compact structure design, the reach truck supports heavy duty operations.
2. Lower center of gravity ensures stability.
3. Wide view masts provide operators with clear visibility.
4. Masts are detachable from the truck frame, and comes with good interchangeability.
5. Low step height and sensitive dead-man's pedal ensure comfortable and safe operation.
6. Narrower overhead guard towards front ensures less possibility to get “hooked” into something.
7. Supporting 360 degree steering, the electric reach truck offers smallest turning radius of 1,800mm.
8. Adjustable steering wheel and arm support largely improve the comfortableness of operators.
9. Drive wheel and balanced wheel are combined together to ensure stability.
Specifications of the Reach Truck
Model Number: CQD10M/15M
Rated Capacity: 1000/1500kg
Mast: Basic 2-Stage Mast (3m)
Mast optional: Triplex (3.5m-7m)
Side Shift (optional): Integral side shift/Cascade side shift
Technical Parameters of Diesel Forklift
| Model | Unit | CQD20 |
| Powe type | Battery | |
| Drive type | sit-down | |
| Load capacity | kg | 2000 |
| Weight (with battery) | kg | 3450 |
| Tyre quantity | 1×+2 | |
| length | mm | 2510 |
| width | mm | 1510 |
| height | mm | 2200 |
| Reach distance | mm | 535 |
| Minimum Aisle Width(Pallet 1100*1100) | mm | 2991 |
| Load center distance | mm | 500 |
| Wheelbase | mm | 1500 |
| Minimum turning radius | mm | 1820 |
| Maximum travel speed (full load/no load) | km/h | 12/14 |
| Maximum lift speed(full load/no load) | mm/s | 350/450 |
| Maximum lowering speed(full load/no load) | mm/s | 500/450 |
| Reach speed(full load/no load) | mm/s | 160/200 |
| Service brake | Hydraulic | |
| Steering type | electric powering steering | |
| Driving motor power | Kw | 8 |
| Lifting motor power | Kw | 12.5 |
| Battery volatage/capacity | V/Ah |
Related Information
Brand: JAC
Target Market: Global market
Certificate: CE/SGS/ISO 9001/ISO 14001/SGS
Production Capacity: 20,000 sets per year
