Product Details:
|
| Power: | Diesel Engine | Load Capacity: | 13.5T |
|---|---|---|---|
| Load Center: | 500mm | Lift Height: | 3000~5000mm |
| Fork Length: | 1220mm | Condition: | New |
| Min. Lifting Height: | 3000mm | Weight: | 4300KGS,1500Kg-4150kg |
| Highlight: | Counterweight Diesel Forklift Truck,13.5T Diesel Forklift Truck,13.5T forklift material handling |
||
Diesel Forklift (13.5T Internal Combustion Counterweight Forklift Truck, )
Product description
Electro-hydraulic gearbox features easy operation. The CPCD120 is integrated with multi-plate clutch for quick speed control,enabling stable operation.
Reinforced drive axle enables it to be more suitable for use under harsh working conditions.
A protective sleeve is added to the steering cylinder to reduce the external force damage of the cylinder.
Low-loss multi way valve application ensures lifting system efficiency is increased by 10%, oil temperature decreased by 12 ℃.
Features
1. Scientifically designed power transmission system
2. Dedicated twin axle for heavy-load lift truck.
3. Reliable hydraulic system.
4. Ratchet-type brake system requires less effort from the operator to set.
Technical Parameters of Diesel Forklift
| Model | Unit | CPCD135 | CPCD150 | CPCD160 | CPCD180 |
| Power type | Diesel | ||||
| Rated load | kg | 13500 | 15000 | 16000 | 18000 |
| Load center distance | mm | 600 | 900 | ||
| Lift height | mm | 3000 | 4000 | ||
| Free lift height | mm | 85 | 100 | ||
| Fork size L×W×T | mm | 1820×200×85 | 2400×250×90 | ||
| Minimum turning radius | mm | 4750 | 5250 | ||
| Maximum travel speed /Full load | km/h | 20 | 18 | ||
| Maximum travel speed/ No load | km/h | 24 | 20 | ||
| Fork height at maximum lift (with backrest) | mm | 4725 | 5845 | ||
| Standard Mast height | mm | 3230 | 3850 | ||
| Front wheel | 11.00-20-18PR | 12.00-24-24PR | |||
| Rear wheel | 11.00-20-18PR | 12.00-24-24PR | |||
| Wheelbase | mm | 3000 | 3800 | ||
| Front wheel/rear wheel | mm | 1950/2050 | 1968/2248 | ||
| Self weight/Without load | Kg | 19500 | 25000 | 25000 | 26600 |
| Battery/ Voltage/capacity | V/Ah | 24/150 | |||
| Engine/ Model | CA6DF3 Xichai,China | YC6J175-T302 Yuchai,China(QSF6.7 Cummins,USA) | |||
| Engine/Rated output | kw/r.p.m | 118/2200 | 129/2200(142/2300) | ||
| Engine/ Rated torque | Nm/r.p.m | 640/1500 | 710/1600-1800(930/1500) | ||
| Tire type (FR/RR) | Pneumatic | ||||
| Number of wheels (FR/RR) | 4/2 | ||||
Related Information
Brand: JAC
Target Market: Global market
Certificate: CE/SGS/ISO 9001/ISO 14001/SGS
Production Capacity: 20,000 sets per year
